Commins Caterm V4.7 – ECM Calibration Terminal Professional

Commins Caterm V4.7 – ECM Calibration Terminal Professional

Calibration Terminal v4.7

Commins Caterm v4.7.1.007 is an engineering development and testing tool used to monitor the Electronic Control Module (ECM) for Cummins engine systems and to alter the calibration data contained therein.

Key Functions

• Perform Installation Quality Assurance testing
• Perform DPF regeneration
• View active and inactive fault codes
• Troubleshoot integration and calibration issues
• Collect engine and AT test data
• Monitor ECM or any J1939/Datalink device parameters
• Temporarily change calibrations
• View and erase fault codes
• Log ECM and J1939/Datalink parameters

When to Use Caterm Instead of lNSITE?

• Access additional parameters in the ECM not available in INSITE
• Log data at a faster rate
• Temporarily change calibrations and override parameters during testing

Supported DLA Kits

Commins Inline 7 Data Link Adapter

Software Configuration Files

• .e2.m — Core 1 products (EPA 2004 and below)
• .ecf.g — Core 2 products (above EPA 2007)

System Requirements

• Windows 7, 8.1, 10, 11 (x86/x64)
• At least 5 GB free HDD space
• Cummins hardware interface required to connect vehicle ECM to Calterm software

Instant download after payment — high-speed download link provided.
